Main
Run time for load
410
W
Min-max: 41-410 W
0min 43s
Max. Capacity Used
100 %
Main Input Voltage
230 V
Rated power in W
410 W
rated power in VA
750 VA
Product or component type
Uninterruptible power supply (UPS)
Input Connection Type
IEC 60320 C13
output connection type
4 IEC 60320 C13
Cable length
1.2 m
Number of cables
1
Battery type
Lead-acid battery
Range of product
Back-UPS
Batteries & Runtime
Run Time
View Runtime Graph
Efficiency
View Efficiency Graph
Number of battery filled slots
0
Number of battery free slots
0
Battery recharge time
8 h
Battery voltage
12 V
Battery capacity
7.0 Ah
Battery life
3…5 year(s)
Replacement battery
RBC17
Battery graph comments
Curve fit to measured runtime data. All measurements taken with new, fully charged batteries, at typical environmental conditions, with no electrical input and balanced resistive load (PF = 1.0) output.
Extended runtime
0
General
Provided equipment
user manual
Number of power module free slots
0
Number of power module filled slots
0
Redundant
No
Physical
Colour
Black
Height
16 cm
Width
12 cm
Depth
35.5 cm
Net weight
5.4 kg
Mounting preference
No preference
Mounting mode
Not rack-mountable
Two post mountable
0
USB compatible
No
Input
Network frequency
50/60 Hz +/- 5 Hz auto-sensing
Plug standard
C14
Input voltage limits
140...300 V
Input Power Factor at Full Load
0.63
Output
Maximum configurable power in W
410 W
Output frequency
50/60 Hz +/- 1 Hz sync to mains
UPS type
Line interactive
Wave type
Stepped approximation to a sinewave
Full load runtime
00:01:00 390 W
Half load runtime
00:08:30 195 W
Maximum configurable power in VA
750 VA
Transfer time
6 ms typical : 10 ms maximum
Conformance
Product certifications
CE
CB
EAC
Standards
EN/IEC 62040-1:2019/A11:2021
EN/IEC 62040-2:2006/AC:2006
EN/IEC 62040-2:2018
Environmental
Ambient air temperature for operation
0…40 °C
Relative humidity
0…95 % non-condensing
Operating altitude
0...3000 m
Ambient air temperature for storage
-15…40 °C
Storage Relative Humidity
0…95 % non-condensing
Storage altitude
0…3000 m
Acoustic level
40 dBA
IP degree of protection
IP20
Communications & Management
control panel
LED Status display with on line : on battery
Surge Protection and Filtering
Surge energy rate
273 J
Packing Units
Unit Type of Package 1
PCE
Number of Units in Package 1
1
Package 1 Height
25 cm
Package 1 Width
43 cm
Package 1 Length
19.7 cm
Package 1 Weight
5.9 kg
SCC14
10731304410796
Contractual warranty
Warranty
2 years repair or replace
