Main
Run time for load
1980
W
Min-max: 198-1980 W
3min 53s
Max. Capacity Used
100 %
Main Input Voltage
230 V
Product or component type
Uninterruptible power supply (UPS)
Other Input Voltage
220 V
240 V
Main Output Voltage
230 V
Other Output Voltage
220 V
240 V
Rated power in W
1980 W
rated power in VA
2200 VA
Input Connection Type
BS1363A British
IEC 60320 C20
Schuko CEE 7 / EU1-16P
output connection type
8 IEC 60320 C13
2 IEC Jumpers
2 IEC 60320 C19
Cable length
2.4 m
Number of cables
1
Provided equipment
CD with software
Country-specific detachable power cord
Documentation CD
Installation guide
Removable support feet
USB cable
Warranty card
Range of product
Smart-UPS On-Line
Batteries & Runtime
Run Time
View Runtime Graph
Efficiency
View Efficiency Graph
Battery type
Lead-acid battery
Battery voltage
72 V
Extended runtime
1
Number of battery filled slots
1
Number of battery free slots
0
Battery recharge time
3 h
Number of battery replacement quantity
1
Battery life
3…5 year(s)
Replacement battery
APCRBC141
Battery charger power
122 W rated
General
Number of power module
1400
Number of power module filled slots
0
Number of power module free slots
0
product web sub-family
High density
Redundant
No
UPS type
Double conversion online
Physical
Colour
Black
Height
43.2 cm
Width
8.5 cm
Depth
58.4 cm
Net weight
25 kg
Mounting location
Front
Mounting preference
Lower
Mounting mode
Rack-mounted with kit
Two post mountable
0
USB compatible
Yes
Mounting position
Vertical
Input
Input voltage limits
100...275 V adjustable (half load)
Network frequency
40...70 Hz auto-sensing
Output
Bypass type
Internal bypass (automatic and manual)
Crest factor
3 : 1
Harmonic distortion
Less than 2 %
Maximum configurable power in VA
2200 VA
Maximum configurable power in W
1980 W
Wave type
Sine wave
Output frequency
50/60 Hz +/- 3 Hz sync to mains
Additional information
Configurable for 220 : 230 or 240 nominal output voltage
Conformance
Product certifications
CE
EAC
RCM
VDE
UK PSTI
Marking
CE Mark
Standards
EN/IEC 62040-1:2019/A11:2021
EN/IEC 62040-2:2006/AC:2006
EN/IEC 62040-2:2018
Environmental
Acoustic level
55 dBA
Heat dissipation
703 Btu/h
Operating altitude
0...10000 ft
Ambient air temperature for operation
0…40 °C
Ambient air temperature for storage
-15…45 °C
Storage altitude
0.0000000000…15240.0000000000 m
IP degree of protection
IP20
Relative humidity
0…95 % non-condensing
Storage Relative Humidity
0…95 % non-condensing
Communications & Management
Emergency power off
Yes
Free slots
1
Alarm
Audible and visible alarms : prioritized by severity
Surge Protection and Filtering
Surge energy rate
340 J
Packing Units
Unit Type of Package 1
PCE
Number of Units in Package 1
1
Package 1 Height
24.600 cm
Package 1 Width
59.900 cm
Package 1 Length
81.000 cm
Package 1 Weight
30.840 kg
Unit Type of Package 2
P12
Number of Units in Package 2
2
Package 2 Height
55.000 cm
Package 2 Width
80.000 cm
Package 2 Length
120.000 cm
Package 2 Weight
74.000 kg
Contractual warranty
Warranty
3 years repair or replace (excluding battery) and 2 years for battery
