Main
Run time for load
5000
W
Min-max: 500-5000 W
2min 50s
Max. Capacity Used
100 %
Main Input Voltage
230 V
Product or component type
Uninterruptible power supply (UPS)
Other Input Voltage
220 V
240 V
Main Output Voltage
230 V
Other Output Voltage
220 V
240 V
Rated power in W
5000 W
rated power in VA
5000 VA
output connection type
2 IEC 60320 C13
1 IEC 60320 C19
Output connector type
Hard wire 3-wire (1P + N + E) 1
Number of rack unit
4U
Provided equipment
1 x USB cable
1 x RJ45 cable
1 x rack mounting brackets
1 x stabilization/wall mounting feet
1 x installation manual
1 x C13-C14 power cord
Range of product
Smart-UPS On-Line
Batteries & Runtime
Run Time
View Runtime Graph
Efficiency
View Efficiency Graph
Battery type
Lead-acid battery
Battery voltage
+/- 96 V
Extended runtime
1
Number of battery filled slots
2
Number of battery free slots
0
Battery recharge time
4 h
Number of battery replacement quantity
1
Battery life
3…5 year(s)
Replacement battery
APCRBC170
Battery charger power
239 W rated
General
Number of power module filled slots
0
Number of power module free slots
0
Redundant
No
UPS type
Double conversion online
Physical
Colour
Black (RAL 9005)
Height
17.5 cm
Width
44 cm
Depth
62 cm
Net weight
55.9 kg
Mounting preference
Lower
Mounting mode
Rack-mounted with kit
Two post mountable
0
USB compatible
Yes
Mounting position
Horizontal
Input
Maximum input current
30 A
Switching current capacity
40 A
Input voltage limits
160...285 V full load
100...285 V half load
Number of input connectors
1 hard wire 3-wire (1P + N + E)
Network frequency
40...70 Hz auto-sensing
Output
Bypass type
Internal bypass (automatic and manual)
Crest factor
3 : 1
Harmonic distortion
Less than 2 %
Maximum configurable power in VA
5000 VA
Maximum configurable power in W
5000 W
Wave type
Sine wave
Efficiency
93.5 %
Output frequency
50/60 Hz +/- 4 Hz sync to mains
Additional information
Configurable for 220 : 230 or 240 nominal output voltage
Conformance
Product certifications
CE
UKCA
TISI
Standards
EN/IEC 62040-1:2019/A11:2021
EN/IEC 62040-2:2006/AC:2006
EN/IEC 62040-2:2018
Environmental
Acoustic level
55 dBA
Heat dissipation
1108.95 Btu/h
Operating altitude
0...3000 m
Ambient air temperature for operation
0…40 °C
Ambient air temperature for storage
-15…45 °C
Storage altitude
0…15000 m
IP degree of protection
IP20
Relative humidity
0…95 % non-condensing
Storage Relative Humidity
0…95 % non-condensing
Communications & Management
Emergency power off
Yes
Preinstalled device
Network management card 3 with environmental monitoring
Alarm
Alarm when on battery : distinctive low battery alarm : overload continuous tone alarm
Surge Protection and Filtering
Surge energy rate
600 J
Packing Units
Unit Type of Package 1
PCE
Number of Units in Package 1
1
Package 1 Height
27.5 cm
Package 1 Width
79 cm
Package 1 Length
59 cm
Package 1 Weight
61.8 kg
Contractual warranty
Warranty
3 years repair or replace (excluding battery) and 2 years for battery
