36 Autosensing 10/100/1000 ports (IEEE 802.3 Type 10BASE-T, IEEE 802.3u Type 100BASETX, IEEE 802.3ab Type 1000Base-T PoE+); Duplex: 10BASE-T/100BASE-TX:half or full;1000BASE-T:full only
4 Combo 10/100/1000BASE-T PoE+ or 100/1000Mbps SFP
8 802.3bz 100M, 1/2.5/5GBASE-T and 10GBASE-T copper PoE+ ports
Additional ports and slots
1 Dual Personality (RJ-45 or USB Micro-B) serial console port
1 USB A port for uploading/downloading files
1 100BASE-T Out of Band Management Port
1 Uplink Slot
1 Stacking Module Slot
2 Power Supply Slots (power supplies not included)
Physical characteristics
Dimensions
1.73" (Height) x 17.42" (Width) x 12.77" (Depth) (4.39cm x 44.25cm x 32.43cm)
Weight
9.81 lbs 4.45 kg
Memory and processor
Dual Core ARM Cortex A9 @ 1016 MHz
1 GB DDR3 SDRAM
Packet Buffer Size: 12.38MB and 4.5MB Ingress/7.875MB Egress
32°F to 131°F (0°C to 55°C) up to 5000ft, 32°F to 122°F (0°C to 50°C). Derate -1 degree C for every 1000 ft from 5000 ft to 10000 ft
Operating relative humidity
15% to 95% (Non-condensing) 10,000 ft
Non-operating/Storage temperature
-40°C to +70°C up to 15000 ft
Non-operating/Storage relative humidity
90% at 65C (non-condensing); 15,000 ft
Acoustic
Sound Power LWaD=4.4 Bel, Sound Pressure LpAm, Bystander = 26.0 dB
Primary Airflow direction
Port to Power
Electrical Characteristics
Frequency
50/60Hz
Maximum Heat Dissipation
457 BTU/hr
482 kJ/hr
Voltage
JL086A PSU:
100-127/200-240 VAC
JL087A PSU:
110-127/200-240 VAC
Current
JL086A PSU (each): 5.3/2.6A
JL087A PSU (each): 9A/4.5A
Maximum power rating
JL086A PSU (each):495W
JL087A PSU (each): 855W
Idle Power
90W
PoE Power (Max Possible)
1440 Watts
Hibernate Power
25W
Notes:Idle power is the actual power consumption of the device with no ports connected. Maximum power rating and maximum heat dissipation are the worst case theoretical maximum numbers provide for planning the infrastructure with fully loaded PoE (if equipped), 100% traffic, all ports plugged in, and all modules populated.
