Chassis and Design
Chassis: 3.5" Chassis with up to 12 Hard Drives (SAS/SATA)
Form Factor: 2U Rack Server
Bezel: Standard Bezel for 2U Chassis
Rails: ReadyRails Sliding Rails Without Cable Management Arm
Processor
CPU: Intel® Xeon® Silver 4514Y (16 cores, 32 threads, 2.0 GHz base frequency, Turbo, HT, 150W TDP, DDR5-4400)
Additional Processor: Not supported in this configuration
Thermal Configuration: High-Performance Heatsink for 1 CPU configuration
Memory
Type: DDR5 5600MT/s RDIMMs
Installed Capacity: 32GB (1x 32GB RDIMM, Dual Rank)
Performance: Optimized for high throughput
Storage
Drive:
480GB SSD SATA Read Intensive (6Gbps, 512n, 2.5in Hot-Plug, Hybrid 3.5in Carrier, 1 DWPD)
RAID Controller: PERC H755 Adapter LP
RAID Configuration: Unconfigured RAID (C7, supports mixed drive types)
Power Supply
PSU: Dual, Hot-Plug, Fully Redundant (1+1), 700W Titanium Efficiency (200-240V only)
Power Cords: 2x Rack Power Cord 2M (C13/C14, 10A)
BIOS and System Management
BIOS:
UEFI Boot Mode with GPT Partition
Power Saving BIOS Settings Enabled
Embedded Management: iDRAC9 Enterprise (16G)
Quick Sync: Not included
Group Manager: Disabled
Networking
Integrated NIC: Broadcom 5720 Dual Port 1Gb On-Board LOM
OCP 3.0 NIC: Not included (blank filler)
Fans
Configuration: High-Performance Fan x5 for optimal cooling
Expansion Slots
PCIe Riser: Riser Config 0, No Riser (1x PCIe x16 + 1x PCIe x8 slots for 1 CPU)
Trusted Platform
TPM: Trusted Platform Module (TPM) 2.0 V3
Software and Documentation
Operating System: Not included
OS Media Kit: Not required
Documentation: No Systems Documentation, No OpenManage DVD Kit
Shipping and Regulatory
Shipping Materials:
PowerEdge R760xs/HS5620 Shipping Material
Region: EMEA2 (English/Slovenian/Slovakian/Polish/Czech/Hungarian/Greek/Arabic)
Regulatory Markings: CE and CCC Marking (for below 1300W PSU)
Warranty and Support
Standard Warranty: Basic Next Business Day Support for 36 Months
Additional Options:
ProSupport with 4-Hour Onsite Service for 36 Months
Keep Your Hard Drive for Enterprise Services (optional)
